FIRE SPRINKLER AND SUPPRESSION SYSTEM DESIGN, BIM COORDINATION AND 3D MODELING, FIRE PUMP AND STANDPIPE DESIGN

Welcome to 3D Fire Design, LLC | 3-Dimensional and Non-3 Dimensional Fire Protection Designs

3D Fire Design specializes in fire sprinkler design, fire system designs, suppression and related systems. We are proud to offer both non 3-Dimensional design as well as 3-Dimensional design (modeling) and coordination. Our nationwide and international clients range from medical centers, warehouse facilities, condominiums, high rise office buildings, community centers, among many other large-scale organizations and business. VIew some sample projects to get a feel for our workflow and quality in design services.

Click on image to enlarge

We are fully NICET IV certified, and have extensive experience with all types of construction. We also carry extensive knowledge of the NFPA standards which is used to design the best and most efficient sprinkler systems possible. 3D Fire Design is proud to bring experience which ranges from Estimation (sales), Design Management, Project Management, & Lead Design.

All Sprinkler Plans Include:

  1. Calculations
  2. Seismic Calcs, Details, and Print-outs (as needed)
  3. Dimensions, elevations, sections, details, main tags, & line tags
  4. Color Codes
  5. Installation notes to provide fitters with everything they need for a complete installation.

Fire Sprinkler Plans are created using MEPCAD’s AutoSPRINK Software.

Fire protection plans are drawn automatically in a 3D object based environment using realistic pipe, fittings and devices for more accurate designs, fabrication and installations.

HAVE REVIT? No problem. I actually prefer Revit Files. As well, MEPCAD now offers a Revit Add-in that will export a Revit 3D view .rvt file to a .mrv file, which is an AutoSPRINK intelligent file allowing the fire sprinkler system to be designed in a true 3D version of the building and structure instead of the limited 2D flat version.

Download Revit Import-Export MRV add-in here

Visit MEPCAD's website or ask me about this.

Available Software:

  1. MEPCAD AutoSprink v12 Platinum
  2. AutoPREP
  3. AutoDesk Autocad (Architectural and Mechanical) 2012
  4. AutoDesk Revit Architecture 2012
  5. AutoDesk Navisworks Manage 2011 & Freedom
  6. TyCode (Tyco Code Reference Software)
  7. Tol-Brace (Seismic Calculation Software)
Screen Capture Software
